Bottom Glass Patch

Bottom Glass Patch Specification

Usage & Applications
Glass Door Patch Fitting

Anti Corrosion
Yes

Glass Type
Tempered Glass Compatible

Function
Secures bottom of glass door

Security Features
Robust Stainless Steel Construction

Standard
Industry Standard

Finish Type
Brushed / Satin Finish

Surface Finish
Brushed / Satin

Operating Temperature
-10C to 60C

Load Capacity
Up to 80 kg (approx., depends on model)

Operation Type
Manual

Coating Type
Anti-corrosive Coating

Height
30 mm

Weather Resistance
Yes

Glass Thickness
8mm to 12mm

Tensile Strength
High

Width
50 mm

Product Type
Bottom Glass Patch

Material
Stainless Steel

Size
160mm.x 50mm.x30mm.

Color
Silver

Application
Glass Door

Mounting Type
Bottom Mounted

Design Type
Modern Minimalist

Installation Type
Bottom Patch Fitting (Glass Mount)

Locking Type
Non-Locking

Fire Rating
Not Rated for Fire

Compatible Accessories
Suitable for use with overpanel or side panel patches

Packaging Type
Box

Hardware Type
Glass Door Patch Fitting

Corrosion Resistance Grade
304 Stainless Steel

Bottom Glass Patch Trade Information

Minimum Order Quantity
10 Pieces

Supply Ability
5000 Pieces Per Month

Delivery Time
7 Days

About Bottom Glass Patch

Usage/Application	Glass Door
Brand	Bricon England
Size	160mm.x 50mm.x30mm.
Material Grade	SS 304
Finished	Polished
Packaging Type	Box
Material	SS
Country of Origin	Made in India

High-Quality Stainless Steel Construction

Manufactured from premium 304 stainless steel, the Bottom Glass Patch ensures exceptional durability and excellent resistance to corrosion in varying weather conditions. The brushed or satin finish not only adds a sleek touch to your glass door installations but also supports long-term reliability. This makes it suitable for frequently used indoor and outdoor environments.

Seamless Glass Door Integration

Designed for tempered glass panels between 8mm and 12mm thick, the fitting is easily installed as a bottom patch. Its modern minimalist design complements contemporary architecture, while compatibility with overpanel or side panel patches expands its functional versatility. The bottom-mounted patch fitting process is straightforward for professional installers.

Reliable Performance and Safety

The product's robust structure provides high tensile strength and a load capacity up to 80 kg, depending on the model. The anti-corrosive coating and industry-standard manufacturing further ensure dependable operation across various temperature ranges. Although non-locking, its sturdy construction secures the bottom of glass doors efficiently.

FAQ's of Bottom Glass Patch:

Q: How do I install the Bottom Glass Patch on a glass door?

A: Installation involves securing the patch fitting at the bottom edge of a tempered glass door. Professional installation is recommended to ensure proper alignment, correct mounting of accessories, and optimal performance with glass thickness ranging from 8mm to 12mm.

Q: What type of glass is compatible with this patch fitting?

A: This product is designed specifically for tempered glass panels with a thickness of 8mm to 12mm. It ensures a snug and secure fit, ideal for contemporary glass door applications.

Q: When should I use this patch fitting instead of other types of hardware?

A: Choose this bottom patch fitting when you require a secure, bottom-mounted solution for glass doors needing robust support, particularly when compatibility with overpanel or side panel patches is required in modern building projects.

Q: Where can the Bottom Glass Patch fitting be used?

A: It is suitable for installation in both residential and commercial spaces, including offices, hotels, and retail stores where glass doors enhance the aesthetic and functional design.

Q: What benefits does the 304 stainless steel construction offer?

A: 304 stainless steel provides high corrosion resistance, exceptional tensile strength, and long-lasting durability, making it ideal for both indoor and outdoor glass door installations.

Q: What is the maximum weight load this fitting can support?

A: The Bottom Glass Patch is designed to support glass doors weighing up to 80 kg, depending on the model and correct installation.

Q: Does this glass patch fitting provide any security features?

A: While it does not include a locking mechanism, the robust stainless steel construction ensures strong support and resistance against forced entry, contributing to overall door integrity.
